Score 0-199, game time 00:00-99:59, number height - 15 cm, visibility 50 m.
Periods 0-9, E, fouls/sets won 0-9, number height - 15 cm, visibility 50 m
Minute breaks are represented by 3 green stars – 1.5cm in diameter.
Ball control and direction are represented by a red 1 star 1.5 cm in diameter.
Timer: from 00:00 to 99:59. Counts up and down, shows time, 1/10 second display in the last minute of the match (used in water polo, basketball, etc.).
Shows the time of day;
Audible signal at time out: 85db at a distance of 2 m.
Viewing angle 150°.
No additional protection is required, the scoreboard coating meets the requirements of DIN18032-3 and UNI 9554:1989 standards for ball impact resistance.
Made of sturdy aluminum body.
SMD LED average working life is 100,000 working hours.
The light board uses 100-240V 85VA power supply.
Lightbox dimensions: 91x60x9.5 cm.
The weight of the light board is 10 kg.
Control panel: Console-700 (wireless, wired connection),
Warranty - 2 years.
