Game time: [00:00 - 99:59], 30cm high digits
Command points: [0-199], 30cm high digits
Number: [0-9], 30cm high digit.
Team fouls / Sets won: [0-9], 30cm high digits
Bonus: [1 indicator per team], 8cm in diameter.
Breaks: [3 indicators per team], 8cm diameter.
Ball position/Serving/Line: [arrows].
Programmable command names: FS-120N model only, 8 characters per command, 15.5cm high
• Dimensions: 200x180x9cm.
• Weight: 60kg [FS-120], 66.5kg [FS-120N].
• Visibility distance and angle: 130m (425ft), 150 nits. For the FS-120N model, visibility of team names up to 90m (295ft).
• FIBA approval ( info , FIBA certificate ). Can be used with other products to create a larger scoreboard for displaying various data ( info ).
• No additional protection required. Meets DIN 18032-3 and UNI 9554 standards for ball impacts. You save by not buying additional protection, you do not reduce visibility, and access to the scoreboard remains easy. YouTube video
• Game timer. Using the Console 700 control panel, the main timer can perform several different functions depending on the selected sport: game time, intervals, countdown or countdown, displaying the last minute in tenths of a second, time of day, etc.
• The siren can be triggered manually or automatically after a timeout (120dB at 1m). The signal intensity and duration are adjustable.
• Easy installation. Technical instructions in five languages. Wall mounting elements included.
• Robust housing made of powder-coated aluminum. Front cover made of anti-reflective polycarbonate.
• The set includes a 50m control cable for connection to the control panel. You can choose different lengths when ordering. For wireless control of the light board, you must additionally purchase a radio receiver (see Accessories).
• Excellent visibility. Wide-angle, high-quality SMD LEDs with an average operating life of 100,000 even hours.
• Moisture-resistant coating. You can additionally order a special moisture-resistant coating for the scoreboard. Recommended if the scoreboard is located in a swimming pool or ice arena.
• Warranty: 2 years.
• Power supply: 100-240Vac, 50-60Hz, 210VA [FS-100] / 260VA [FS-100N].
